EFG 213-220 / EFG 316k-320 3-Wheel/4-Wheel Electric Pneumatic Tire Lift Trucks
The EFG-316k-320 four-wheel forklift series provides high performance and energy efficiency utilizing 4th generation AC technology.
These 3,000-4,000 lb. capacity lift trucks are equipped with the newest generation of AC technology and feature efficient electric power steering. Industry-leading drive and lift performance levels and the ability to run up to two shifts on a single battery charge in most applications further reduce maintenance requirements and provide a lower total cost of ownership.
This forklift is equipped with three performance settings, allowing it to be adapted to match operator preferences.
Experience increased productivity due to the forklift's highly informative, full color interactive display.
Curve Control on these four-wheel forklift trucks automatically reduces speed while turning corners, helping to ensure control over loads.
Multiple warning and light options increase awareness and visibility in the warehouse.
Orange seat belt helps increase awareness and easy visual verification.
Truck performance software can be adjusted to meet your specific drive and hydraulic performance needs or limits.
The energy-efficient design allows the forklift to operate up to two shifts on one battery charge in most applications. This results in increased productivity when operators can work longer without stopping to recharge throughout the work day.
Features regenerative braking, designed to recover lost energy during plugging, braking and coasting. The energy is channeled back into the lift truck's battery, extending operating time and reducing charging time.
Electronic hydraulic controls offer the highest level of operational ease.
SOLO- or MULTI-PILOT hydraulic controls are available to match operational preferences of operators to maximize their productivity.
The full-suspension seat helps to cushion the operator from vibrations and bumps when traveling over uneven surfaces.
Electric power steering (optional on some models) allows the operator to maneuver the truck with very little effort.
Major electrical components are sealed such as connectors, controllers and motors, decreasing the chance of external dust and debris from entering critical forklift areas.
Industry-leading service tool allows Jungheinrich technicians to quickly access and check major truck functions for faster service.
Expect more from Jungheinrich, the experts in warehouse products, like a 5-year / 10,000 hour powertrain warranty that outperforms others. Available on all Jungheinrich Class I and II products sold across the United States, Canada and Mexico, the coverage includes parts and labor on all forklift components. Rest easier knowing that we’re here to help keep your fleet running – shift after shift – when you need it most.
Let us help you find the right solution to optimize your warehouse productivity.
Model | Basic Capacity (lbls) | Max Fork Height | Voltage (or Fuel Type) | Length to Fork Face | Chassis Width (in) | Chassis Height (in) | Gross Weight (lbls) |
EFG 316k | 3,100 | 255 | 36/48 | 78.3 | 41.7 | 80.4 | 6,601 |
EFG 316 | 3,100 | 255 | 36/48 | 82.6 | 41.7 | 80.4 | 6,537 |
EFG 318k | 3,490 | 255 | 36/48 | 78.3 | 44.1 | 80.4 | 6,964 |
EFG 318 | 3,490 | 255 | 36/48 | 82.6 | 44.1 | 80.4 | 6,900 |
EFG 320 | 3,880 | 255 | 36/48 | 82.6 | 44.1 | 80.4 | 7,253 |
